SPECIFICATION
Delivery Line | DN 125 / 5 | DN 125 / 5 | Proportional control |
---|---|---|---|
Wear plate / Ring | Tungsten Carbide | Water Pump | 20 Bar |
Water Tank | 500 Liter | Auto Lubrication | Hyd. grease, Hopper |
Output | Rod 177 ㎥/h / Piston 120 ㎥/h | Pressure | Rod 87 Bar / Piston 130 Bar |
Delivery Cylinder (Hard-chromed) | Φ230 mm | Stroke Length | 2100 mm |
S - Valve | S2018 | System Pressure | 350 Bar |
Switching Type | Hydraulic | Hopper Capacity | 600 Liter |
Number of booms | 6 Sections | Folding Type | R & Z TYPE |
Vertical Height | 59.2 m | Horizontal Reach | 54.2 m |
Unfolding height | 16.2 m | End-Hose Length | 4.0 m |
