建設機械コンクリートポンプ車 70 ~ 50M

Extremely powerful concrete pump with 5Section RZ Fold

Delivery Line	DN 125 / 5	Radio remote	Proportional control
Wear plate / Ring	Tungsten Carbide	Water Pump	20 Bar
Water Tank	600 Liter	Auto Lubrication	Hyd. grease, Hopper
Output	Rod 177 ㎥/h / Piston 120 ㎥/h	Pressure	Rod 87 Bar / Piston 130 Bar
Delivery Cylinder (Hard-chromed)	Φ230 mm	Stroke Length	2100 mm
S - Valve	8 X 7	System Pressure	350 Bar
Switching Type	Hydraulic	Hopper Capacity	600 Liter
Number of booms	5 Sections	Folding Type	R & Z TYPE
Vertical Height	54.8 m	Horizontal Reach	50.1 m
Unfolding height	14.4 m	End-Hose Length	4.0 m
